Two-Person Mild Hyperbaric Oxygen Chamber
2 people · shared chamber

Two-Person Mild Hyperbaric Oxygen Chamber

Higher throughput per installed square metre

  • Electronic valve manifold for pressure control
  • 415 kg/m² floor loading, 1.7 t total shell weight
  • 5-stage 0.1 μm filtration with oxygen concentration sensing
Request a quotation Download specification

Commercial terms depend on configuration and order quantity. Each value below is confirmed in the quotation.

Overview

Two occupants per session. Internal space 1583 × 2183 × 1983 mm, working pressure 1.1–1.5 ATA, controlled by an electronic valve manifold. Total shell weight is approximately 1.7 t and the floor must carry 415 kg/m². Oxygen is generated onboard at 93%, 10 L/min, with 5-stage 0.1 μm filtration. External dimensions are recorded as 1600 × 2200 × 2000 mm and are to be confirmed at order stage. This product is a pressure and oxygen-delivery device and is not a medical device for diagnosis or treatment of disease.

Specifications

Certificates on file cover the tested configuration. Certificate scope and validity are stated in the quotation.

chamber

External dimensions1600 × 2200 × 2000 mm (to be confirmed)
Internal dimensions1583 × 2183 × 1983 mm
Rated occupancy2 people
Design / working pressure1.1–1.5 ATA
Pressure controlElectronic valve manifold
Total shell weightapprox. 1.7 t
Floor loading415 kg/m²
Shell materialCarbon steel (aluminium alloy optional)

interior

LightingDual LED cold-light system + ambient lighting
Oxygen deliveryDiffusion / nasal cannula
Air conditioningIndependent A/C system
SensorsO₂ concentration, temperature, humidity, PM2.5

mainUnit

Oxygen system93%, 10 L/min
Air filtration5-stage filtration, 0.1 μm
Master controlExpandable ARM-based controller

Procurement data

Commercial terms depend on configuration and order quantity. Each value below is confirmed in the quotation.

MOQ
Confirmed in quotation
Depends on model and whether the chamber is factory branded or OEM.
Lead time
Confirmed in quotation
Standard models ship faster than built-to-order multi-unit projects.
Container loading
Confirmed in quotation
We state the 40HQ quantity per model once the configuration is fixed.
Payment terms
Confirmed in quotation
T/T and L/C are both available; the split depends on order value.
Logo customisation
Available on request
Minimum quantity for branded shells is confirmed in the quotation.
Packaging
Export wooden cases
Fumigation and marking can be adapted to the destination market.
Warranty & after-sales
Confirmed in quotation
Core components are replaced rather than repaired. Engineer support on request.
Installation & commissioning
Available on request
Professional installation by our technicians, or guided remote commissioning.

Compliance

Certificates on file cover the tested configuration. Certificate scope and validity are stated in the quotation.

CE
CE
EU conformity assessment

Certificate on file. Applicable directives and the notified body reference are confirmed per order.

FCC
FCC
Third-party test laboratory

File reference LTC230913-CSA-035. Covers the tested configuration; re-testing is quoted if the configuration changes.

CSA
CSA
Third-party test laboratory

File reference LTC230913-CSA-034. Covers the tested configuration; scope is confirmed per order.

ISO 9001 · Quality
ISO 9001 · Quality
Certification body

Quality management system for design, manufacture and service. Certificate number and validity on request.

ISO 14001 · Environmental
ISO 14001 · Environmental
Certification body

Environmental management system. Certificate number, scope and validity on request.

ISO 45001 · OH&S
ISO 45001 · OH&S
Certification body

Occupational health and safety management system. Certificate number and validity on request.

Documentation

Catalogues and certificates are available as PDF. Request the current file revision with your enquiry.

PDF

O2AKSO Product Catalogue (EN)

Full English line sheet with specifications and chamber options.

Download catalog
PDF

Company Profile (CN / EN)

Who we are, manufacturing base, R&D and quality systems.

Download catalog
PDF

Certification Pack

CE, FCC, CSA and management-system certificates.

Download catalog

Frequently asked questions

The questions overseas procurement teams ask us most often, answered without marketing language.

MOQ depends on the model and whether the unit is factory branded or OEM. The exact figure is confirmed in the quotation before you commit.

Standard models have a shorter lead time than built-to-order multi-unit projects. The current lead time is confirmed in the quotation for your configuration.

It depends on model and packaging. We calculate the 40HQ and 20GP quantity for your configuration and state it in the quotation.

The standard supply is 220V / 50Hz. Other voltages, frequencies and plug types are engineered to order and confirmed in the quotation.

The certificates on file cover the tested chamber configuration. We send the certificate copies and the declaration of conformity with your quotation, so you can check scope before ordering.

Yes, logo customisation is available. The minimum order quantity for branded shells is confirmed in the quotation.

Installation by our own technicians is available on request, as is guided remote commissioning. Which option applies is stated in the quotation.

Core components are replaced rather than repaired. Spare part lists, remote monitoring and response times are confirmed in the quotation.
